Graph information
| Field | Internal name | Type | Warning | Critical | Info |
|---|---|---|---|---|---|
| Vcore | volt1 | gauge | 0.61:2.45 | 0.00:3.06 | |
| Vcore SOC | volt2 | gauge | 0.61:2.45 | 0.00:3.06 | |
| in2 | volt3 | gauge | 0.61:2.45 | 0.00:3.06 | |
| in3 | volt4 | gauge | 0.61:2.45 | 0.00:3.06 | |
| in5 | volt5 | gauge | 0.61:2.45 | 0.00:3.06 | |
| in6 | volt6 | gauge | 0.61:2.45 | 0.00:3.06 | |
| 3VSB | volt7 | gauge | 1.22:4.90 | 0.00:6.12 | |
| VBAT | volt8 | gauge |
Zooming is very easy, it's done in 3 clicks (regular clicks, no drag&drop):
- Click to define the start of zoom.
- Click to define the ending of zoom.
- Refresh.
You can use the interactive form too.
