Graph information
| Field | Internal name | Type | Warning | Critical | Info |
|---|---|---|---|---|---|
| Tctl | temp1 | gauge | |||
| Composite | temp2 | gauge | |||
| Sensor 1 | temp3 | gauge | |||
| Sensor 2 | temp4 | gauge | |||
| GPU edge | temp5 | gauge | |||
| System | temp6 | gauge | 75.0 | 80.0 | |
| CPU Socket | temp7 | gauge | 75.0 | 80.0 | |
| CPU | temp8 | gauge | 75.0 | 80.0 | |
| PCH_CPU_TEMP | temp9 | gauge | |||
| PCH_MCH_TEMP | temp10 | gauge | |||
| TSI0_TEMP | temp11 | gauge |
Zooming is very easy, it's done in 3 clicks (regular clicks, no drag&drop):
- Click to define the start of zoom.
- Click to define the ending of zoom.
- Refresh.
You can use the interactive form too.
