Graph information
| Field | Internal name | Type | Warning | Critical | Info |
|---|---|---|---|---|---|
| vddgfx | volt1 | gauge | |||
| vddnb | volt2 | gauge | |||
| Vcore | volt3 | gauge | 0.70:2.79 | 0.00:3.49 | |
| +5V | volt4 | gauge | 4.71:5.30 | 4.51:5.50 | |
| AVCC | volt5 | gauge | 3.11:3.50 | 2.98:3.63 | |
| +3.3V | volt6 | gauge | 3.11:3.50 | 2.98:3.63 | |
| +12.0V | volt7 | gauge | 11.64:12.38 | 11.40:12.62 | |
| VDDCR_SOC | volt8 | gauge | 0.41:1.63 | 0.00:2.04 | |
| DRAM | volt9 | gauge | 0.40:1.60 | 0.00:2.00 | |
| VBATT | volt10 | gauge | 3.11:3.50 | 2.98:3.63 |
Zooming is very easy, it's done in 3 clicks (regular clicks, no drag&drop):
- Click to define the start of zoom.
- Click to define the ending of zoom.
- Refresh.
You can use the interactive form too.
